 Axle codes
Author Message
Administrators
User avatar

Joined: Fri Oct 26, 2007 9:40 am
Posts: 6054
Location: Maynardville, TN
Status: Board Dad
Part of TN: East
Post Axle codes
I did run across this


RPO Ratio Axle Type RPO Ratio Axle Type
H22 6.17 Rear
H23 5.43 Rear
HA3 5.29 Rear
HA5 4.63 Rear
HC2 4.27 Rear
HC4 4.56 Rear
HC7 5.13 Rear
HC8 3.21 Rear
HC9 5.13 Rear
HD1 5.83 Rear
HE3 3.07 Rear
HE4 3.40 Rear
HF7 4.56 Rear
HF8 4.88 Rear
HJ1 4.55 Rear
HJ2 5.86 Rear
HJ3 4.75
HJ4 6.50 Rear
HJ5 5.57 Rear
HJ6 4.78 Rear
HJ7 4.88 Rear
HK1 2.87 Rear
HK3 6.14 Rear
HK9 5.86 Rear
HO4 4.11 Rear
HO6 4.63 Rear

G44 3.07 Rear
G72 2.14 Rear
G75 3.62 Rear
G84 3.70 Rear
G90 3.15 Rear
G91 6.83 Rear
GH0 3.54 Rear
GH1 3.55 Rear
GH2 2.29 Rear
GH3 2.77 Rear
GH4 2.28 Rear
GH7 2.73 Rear
GJ1 5.38 Rear
GJ2 5.13 Rear
GK7 4.78 Rear
GK8 4.33 Rear
GK9 4.63 Rear
GL0 5.13 Rear
GL3 6.17 Rear
GM1 2.59 Rear
GM2 3.44 Rear
GM3 3.45 Rear
GM4 3.67 Rear
GM5 3.89 Rear
GM6 4.22 Rear
GM7 3.68 Rear
GM8 2.56 Rear
GN9 4.11 Rear
GS4 2.70 Rear
GS8 3.94 Transaxle
GT4 3.73 Rear
GT5 4.10 Rear
GT6 4.19 Transaxle
GT7 3.33 Rear
GT8 4.10 Rear
GU1 2.41 Rear
GU2 2.73 Rear
GU3 2.93 Rear
GU4 3.08 Rear
GU5 3.23 Rear
GU6 3.42 Rear
GU7 2.77 Rear
GU8 3.90 Rear
GU9 3.91 Rear
GV0 3.55 Rear
GV2 5.83 Rear
GV3 3.57 Rear
GV4 3.36 Rear
GV5 3.82 Rear
GV7 4.05 Rear
GV8 2.72 Rear
GV9 4.25 Rear
GW4 3.31 Rear
GW6 3.27 Rear
GW9 2.93 Rear
GX3 3.33 Transaxle
GX4 3.75 Rear
GX5 4.09 Rear
GX6 3.53 Rear
GX8 3.74 Transaxle
GY2 4.30 Rear
GY3 4.29 Transaxle
GY4 4.53 Rear
GY5 3.65 Front
GY7 4.18 Transaxle
GY9 4.31 Rear

_________________
Names David but you can call me Woody

74 K5 to be a 2WD, Just a driver
71 C-30 in pieces


Fri Feb 08, 2008 3:57 pm
Profile
Non Residents
User avatar

Joined: Tue Nov 06, 2007 8:24 am
Posts: 1938
Location: TEXAS
Post
Cool list Woody!!

_________________
-Mike Owen-


Fri Feb 08, 2008 4:59 pm
Profile YIM
Administrators
User avatar

Joined: Thu Oct 25, 2007 4:38 pm
Posts: 13079
Location: Beech Bluff, TN
Part of TN: West
Post
Agreed :cool:

_________________
The Toy: "Square Vette" 72 C5 Blazer
Toy Puller: "Burakkubyūtī" 12 Tundra
Toy Hauler: "Feathers" Aluma 8218T
Owner/Admin "TN Classic Truck Club"


Fri Feb 08, 2008 6:36 pm
Profile WWW
Administrators
User avatar

Joined: Fri Oct 26, 2007 9:40 am
Posts: 6054
Location: Maynardville, TN
Status: Board Dad
Part of TN: East
Post
I am going to try to find a list of the codes stamped in the tube, they are different from the RPO codes.

_________________
Names David but you can call me Woody

74 K5 to be a 2WD, Just a driver
71 C-30 in pieces


Fri Feb 08, 2008 10:43 pm
Profile
User avatar

Joined: Tue Mar 22, 2011 10:46 pm
Posts: 777
Location: Jackson, TN
Part of TN: West
Post Re: Axle codes
I looked through this list but could not find any thing on my rear end to match .....????????????
these are the #'s that I have on my 12 bolt under the Blazer....
all #'s are on the housing not the tubes....

passenger side, H218 <--- this is the date it was made

. 3896839 <-----\
. N <------------/ not sure what this is I cant find any info

driver side, GM85 <--- not sure about this one also, it does not match the list above?

I am trying to find out what gear ratio I have with out pulling the cover on the diff.. not sure if these #,s will help me do that or not.

any help would be greatly helpfull and thanks even if it doesn't help

I need to get my speedo working and reading right lol.... I need a new cable and a gear for a th350c but if I remember correctly the th350 is the same as far as this is concerned.

_________________
1978 2wd C10 Stepside
1979 2wd K5 Cheyenne Blazer (work in progress/not sure what is going to happen)
1987 Kawasaki Ninja 1000R (gas saver)


Thu Aug 11, 2011 12:13 pm
Profile
User avatar

Joined: Sun Feb 10, 2008 2:11 pm
Posts: 1674
Location: Oneida, TN
Part of TN: Middle
Post Re: Axle codes
Matt, jack your Blazer up so that the back wheels are off the ground and you can reach the driveshaft. Mark a wheel and the driveshaft so you can see every time they make a complete revolution. Turn the wheel once and count how many revolutions the driveshaft makes, and that should give you an approximation of your gearing (then look up what gear ratios your Blazer came with to figure out exactly what it is).

_________________
Aaron

2004 Matrix XRS
1992 GMC K3500
1987 Land Cruiser FJ60
1970 4x4 Blazer
1956 Chevy big window, shortbed
1954 Ford F-100


Thu Aug 11, 2011 12:44 pm
Profile
User avatar

Joined: Tue Mar 22, 2011 10:46 pm
Posts: 777
Location: Jackson, TN
Part of TN: West
Post Re: Axle codes
ok I still am not having any luck finding out the gear in the rear end.... but I did find the code stamped on the axle tube it is KAS 241W92

_________________
1978 2wd C10 Stepside
1979 2wd K5 Cheyenne Blazer (work in progress/not sure what is going to happen)
1987 Kawasaki Ninja 1000R (gas saver)


Thu Aug 11, 2011 8:06 pm
Profile
Administrators
User avatar

Joined: Thu Oct 25, 2007 4:38 pm
Posts: 13079
Location: Beech Bluff, TN
Part of TN: West
Post Axle codes
Depending on how long you
have owned it & how many
miles are on it, you might
want to have it serviced.

Then check it during!


I-Phone via Tapatalk

_________________
The Toy: "Square Vette" 72 C5 Blazer
Toy Puller: "Burakkubyūtī" 12 Tundra
Toy Hauler: "Feathers" Aluma 8218T
Owner/Admin "TN Classic Truck Club"


Fri Aug 12, 2011 9:49 am
Profile WWW
User avatar

Joined: Tue Mar 22, 2011 10:46 pm
Posts: 777
Location: Jackson, TN
Part of TN: West
Post Re: Axle codes
yea I have been trying to avoid that but its starting to look like thats the only way to find out now... I spent about 5 hours online yesterday trying to find the info on that rear end lol and still could not find any

_________________
1978 2wd C10 Stepside
1979 2wd K5 Cheyenne Blazer (work in progress/not sure what is going to happen)
1987 Kawasaki Ninja 1000R (gas saver)


Fri Aug 12, 2011 11:08 am
Profile
Administrators
User avatar

Joined: Fri Oct 26, 2007 9:40 am
Posts: 6054
Location: Maynardville, TN
Status: Board Dad
Part of TN: East
Post Re: Axle codes
Spent a little time also and didn't find what I was looking for.

_________________
Names David but you can call me Woody

74 K5 to be a 2WD, Just a driver
71 C-30 in pieces


Fri Aug 12, 2011 11:32 am
